Product Description
Quantum Leap in IP Survey Technology: 20kW Systems for Deep-Penetration Surveys
The fourth-generation WDFZ transmitters incorporate 17 patented innovations:
Dynamic current stabilization maintains ±0.05% ripple under 5kΩ·m ground conditions
Multi-harmonic cancellation eliminates cultural noise from power lines/railways
AI-driven fault prediction reduces downtime through component health monitoring
1. Transmitter Performance Benchmark
| Parameter | Competitor A | Competitor B | WDFZ-20T |
|---|---|---|---|
| Max output current | ±15A | ±18A | ±20A |
| Voltage efficiency | 68% | 72% | 89% |
| Weight per kW | 4.2kg/kW | 3.8kg/kW | 2.1kg/kW |
| Waterproof rating | IP55 | IP66 | IP68 |
2. Revolutionary Data Capture
4D inversion capability tracks temporal mineralization changes
Sub-meter positioning via integrated GNSS/INS systems
Petabyte-scale compression stores decade-long project data
Module 1: Critical Mineral Exploration
Rare earth element (REE) detection using spectral IP response curves
Battery metal targeting (Li/Co/Ni) via 0.1Hz-10Hz frequency sweep
Module 2: Environmental Stewardship
Acid-generating sulfide quantification prevents mine drainage risks
Tailings facility monitoring with quarterly IP time-lapse surveys
Module 3: Urban Geotechnical Surveys
Underground utility mapping at 0.5m resolution
Landslide risk assessment through clay content analysis
