Logging Cable 1 Conductor 4.76mm Winch Cable for Geophysical Logging Equipment

Construction

Copper Construction: 7×0.32 mm 7×0.0126〃

Insulation PP: 0.60 mm 0.0236〃

Armor:（Inner） 12×0.61mm(546N) 12×0.0240〃(123 lbs)

（Outer） 15×0.76 mm(848N) 15×0.0251〃(191 lbs)

Physical

Cable Diameter: 4.70mm±0.10mm 0.18″±0.0039″

Cable Weight in Air: 85 kg/km 57.4 lbs/kft

Temp Rating: 150 ℃ 300 ℉

Mechanical

Cable Breaking Strength： 15kN 3375 lbs

Minimum Shave Diameter： 300 mm 11.8″

Cable Stretch Coefficient： 4.78 m/km/5kN 4.25 ft/kft/klbs

Electrical：

Voltage Rating： 1000 VDC 1000 VDC

Insulation Resistance： 1500 MΩ·km 50000 MΩ·kft

Resistance Typical： 33 Ω/km 10 Ω/kft

Capacitance @ 1 kHz: 160 pf/m 48.7pf/ft
